TH110D20ZZ-3G

Main features of the module: Self-cooling module, strong adaptability to the environment, high reliability,MODBUS,TH protocol integration, automatic, manual, independent work three modes, electromagnetic compatibility in line with national standards.

Keywords：

TH110D20ZZ-3G

subclassification：

Electric power supply (self-cooling)

Model：

cp1101

Product consulting：

Product description

Technical parameters:
Weight :9kg
★ Size :230mm × 130mm × 325mm(height × width × depth, without panel connector)
Cooling method: natural cooling
★ Operating temperature :--10℃ ~ 40℃
Ac input voltage VAC:380(-15% ~ 20%)
Dc output voltage VDC:176 ~ 300 (88 ~ 150)
Dc output current A:10 (20)
★ Power factor: ≥ 0.94
★ Efficiency: ≥ 95%
Stability accuracy: ≤ ±0.5%
Stable flow accuracy: ≤ ±1%
★ Peak ripple coefficient: ≤ 0.5%
Noise: ≤ 50dB
Parallel machine uneven mobility: ≤ ±3%
★ Communication mode :RS485

Main features of the module:
Self-cooling module, strong adaptability to the environment, high reliability,MODBUS,TH protocol integration, automatic, manual, independent work three modes, electromagnetic compatibility in line with national standards.
